U-Pole

Smart Light Pole LED Display

1.Convenient management: cluster management, supporting multi-level grouping of terminals and users, and multi-level permission settings for users;
2.Easy to expand: Modular design, easy to expand software functions;
3.Multiple networking: support wired, wireless (WiFi, 3G, 4G) and other networking methods;
4.Real-time information release: immediate release of emergency information; automatic generation of play logs;
5.Content split display: one screen can play text, video and pictures at the same time;
6.Fixed-point delivery function: fixed-point playback, different content can be played on the same screen, and the same content can be played on different screens;
7.Basic function settings: adjustment of screen brightness, audio volume, one-key software version upgrade, etc.

U-Pole



Pixel pitch(mm)

2.5mm

2.5mm

2.5mm

Resolution of module(dot)

128*256 Dots

192*384 Dots

256*512 Dots

Module size(mm)

160*160mm

160*160mm

160*160mm

Display Size(mm)

320*640

480*960

640*1280

External Size(mm)

420*740*105

580*1060*105

740*1380*105

Brightness(CD/m²)

5000~7000CD/m²

5000~7000CD/m²

5000~7000CD/m²

Weight(kg)

13

22

34

Cabinet Material

Cast Aluminum Profile/Sheet Metal

Cast Aluminum Profile/Sheet Metal

Cast Aluminum Profile/Sheet Metal

Control Method

4G/Network Port/WIFI

4G/Network Port/WIFI

4G/Network Port/WIFI

Maintenance Mode

Back Maintenance

Back Maintenance

Back Maintenance

Suitable Post Height(m)

2.5~4

4~6

6~9

Working temperature(℃)

﹣10~40℃

﹣10~40℃

﹣10~40℃

Protect degree(F/B)

IP65

IP65

IP65

Grey / scale(bit)

≥13bit

≥13bit

≥13bit
